Specification:
Working power supply: AC220V + 10%V, 50 + 10%HZ.
Input interface: 12V level signal or pulse width > 100ms 12V pulse signal, drive current > 10mA.
Communication distance: ≤1000mm
Communication interface: RS232 serial interface.
Drive motor: DC24V motor.
Direction: one-way or two-way traffic.
IP protection level: 42.
Opening and closing time: 1 second.
Start time of power on system: 3 second.
Number of people: 40 people / minute.
Normal service life: 4 million times.
Work environment: Indoor/outdoor
Temperature: -40℃ ～ 60℃
Production process: laser cutting
Welcomed OEM/ODM Service
Features and functions:
1) With zero self-test function, convenient for user maintenance and use
2) Illegal entry has an alarm prompt function.
3) Anti-shock function, the swing arm is automatically locked when no open signal is received.
4) Infrared/mechanical double anti-pinch function, when the blade door is in the process of resetting, the motor will automatically stop working within the specified time, and the force is very small, and an alarm is issued at the same time.
5) With automatic reset function, the pedestrian card is valid. If the system does not pass within the specified time, the system will automatically cancel the pedestrian access.
6) Standard external communication interface, which can be connected with a variety of card readers, and can be remotely controlled and managed through a management computer.
