BW-HT03 Full Height Turnstile Gate

Model: BW-HT03
Weight: 700kg
Pass width: ≤600mm
Channel: Dual Channel

Product Details

Specification:
Working power supply: AC220V + 10%V, 50 + 10%HZ.
Input interface: 12V level signal or pulse width > 100ms 12V pulse signal, drive current > 10mA.
Communication distance: ≤1000mm
Communication interface: RS232 serial interface.
Drive motor: DC24V motor.
IP protection level: 42.
Opening and closing time: 1 second.
Start time of power on system: 1 second.
Number of people: 40 people / minute.
Normal service life: 4 million times.
Work environment: Indoor/outdoor
Temperature: -25℃ ~ 70℃
Materical: 304 Grade Stainless Steel
S/S thickness : 2.0mm
Production process: laser cutting
Welcomed OEM/ODM Service

Features and functions:
1) It can be used in all directions without obstacles to prevent pedestrians from passing illegally.
2) Solenoid valve lock, photoelectric sensor unlock function: long service life, high reliability, fast opening speed.
3) With card memory and no memory function (the motherboard button is adjustable). That is, one pass and one pass.
4) The access control software can count the number of people in the traffic direction and present it to the manager to realize the counting function.
5) Anti-crush function: When the switch information is not received, the brake lever is always locked.
6) With automatic reset function, the system will automatically cancel the user's traffic permission when the time is not passed within the specified time. The standard is automatically reset 4 seconds after valid card reading.
7) Standard external air interface, can be connected to a variety of access control attendance equipment, receiving relay switch signal work.
