Specification:
Framework: 304 Grade Stainless Steel
Size: 1200*280*980mm
Weight: 90kg
Arms length: 510mm
Card reading window color:blue/black
Working power: AC220V ±10%V 50±10%HZ.
Direction of passage:single way or double way passage.
Interface: one standard port-RS485
Access method: Swiping card,fingerprint,face recognition,manual button etc.
Relative humidity: ≤90%, no condensation.
Opening and closing time: 1 second.
Power-on system startup time: 1 second.
Number of people: 40 people / minute.
Normal service life: 4 million times.
Work environment: Indoor/outdoor
Temperature: -40℃ ～ 60℃
Production process:laser cutting
Features and functions:
1)Control panel with count and LED digital function
2)Traffic-light: A Red Cross symbol will illuminate to indicate the unit is not available for pass, and a green arrow indicate the direction of allowable passing.
3)Emergency configuration: The tripod will drop automatically by power off or by hand to provide a clear walkway for escape in the event of an emergency.
4)Using solenoid valve lock, photoelectric sensor unlock function,so the turnstile with long service life, high reliability and fast opening speed.
5)With card reader memory and no memory function (the mianboard button is adjustable). That is, one time pass one people and one time pass many people.
6)Anti-crash function: When the switch information is not received, the brake lever is always locked.
7)With automatic reset function, the system will automatically cancel the user's access permission when the time is not passed within the specified time. The standard is automatically reset 4 seconds after valid reading.
8)well in design, rustproof, durable and can resist external destroy.
