Specification:
Working power: AC220V ±10%V 50±10%HZ.
Input interface: 12V level signal or 12V pulse signal with pulse width >100ms, drive current >10mA.
Communication interface: RS232 serial interface,distance ≤1200m.
Drive motor: DC24V motor.
Direction of passage: one-way passage or two-way passage.
Access method: Swiping card,fingerprint,face recognition,manual button etc.
IP protection rating: 42.
Relative humidity: ≤90%, no condensation.
Opening and closing time: 1 second.
Power-on system startup time: 3 seconds.
Automatic reset time after fault: 10 seconds
Number of people: 40 people / minute.
Normal service life: 4 million times.
Work environment: Indoor/outdoor
Temperature: -40℃ ～ 60℃
Production process:laser cutting
Housing material: domestic standard 304 stainless steel. Thickness: National standard 1.2mm~1.5mm.
Net channel width size: stand-alone: standard channel width 550mm, split use: 1100 mm ~ 1600 mm.
The appearance of the housing can be customized according to requirements.
Features and functions:
1) With zero self-test function, convenient for user maintenance and use
2) Illegal entry has an alarm prompt function.
3) Anti-shock function, the swing arm is automatically locked when no open signal is received.
4) Infrared/mechanical double anti-pinch function, when the obstacle is encountered during the reset of the swing arm, the motor automatically stops working within the specified time, and the force is small, and an alarm is issued at the same time.
5) With automatic reset function, the pedestrian card is valid. If the system does not pass within the specified time, the system will automatically cancel the pedestrian access.
6) Standard external communication interface, which can be connected with a variety of card readers, and can be remotely controlled and managed through a management computer.
Extensions:
1) The working status of the programmable device through the built-in buttons on the motherboard.
2) Main board counting function.
3) Powerful voice prompt function.
